LP 46 LITE
TVS-E LP 46 Lite - Desktop Label Printer
LP 46 LITE
ADVANTAGES
Supports both 0.5″ and 1″ ribbon core
Removable black mark reflective sensor
Features
DURABLE AND STRONG DESIGN
HIGH PRINT RATE
AT 6-INCHES PER SEC
HIGH RIBBON CAPACITY OF 300 METRES
USB
INTERFACE
SPECIFICATIONS
Resolution
8 dots/mm 203 DPI
Printing Method
Thermal Line Printing – Direct
Thermal & Thermal Transfer
Print Speed
Max. 152.4 mm 6”/second
Print width
Max. 108 mm 4.25“
Print Length
Physical Dimension
204 mm W x 164 mm H x 280 mm D
Weight
2.4 kg 5.29 lbs
Lable roll capacity
127 mm 5“ OD
Ribbon
300 m long, max. OD 67 mm, 1” core ink coated outside
Ribbon Width
40 mm to 110 mm 1.6” ~ 4.3”
Processor
32bit RISC CPU
Memory
8 MB Flash memory, 16 MB SDRAM
Interface
USB 2.0
Power
Input: AC 100240V, 2.5A, 5060Hz, Output: DC 24V, 2.5A, 60W
Sensors
Transmissive gap sensor, Black mark reflective sensor position adjustable
Barcode
- 1D bar code
Code 128UCC, Code 128 subsets A, B, C, EAN128, Interleaved 2 of 5, Interleaved 2 of 5 with check digit,Code 39, Code 39 with check digit, Code 93, EAN13, EAN8, UPCA, UPCE, EAN and UPC 2 5 digits addon,Codabar, Postnet, MSI, MSI with check digit, PLESSEY, China post, ITF14, Code 11, TELEPEN, TELEPENN,PLANET, Code49, Deutsche Post Identcode, Deutsche Post Leitcode, LOGMARS
- 2D bar code
GS1 DataBar, GS1 DataMatrix, Maxicode, AZTEC, PDF417, QR Code, Micro PDF 417
Printer Language
TSPLEZTM Compatible to EPL, ZPL, ZPL II
Media type
Continuous, diecut, black mark, fanfold, notched outside wound
Media Width
20 ~ 112 mm 0.8“ ~ 4.4“
Media Thickness
0.06 ~ 0.19 mm 2.36 ~ 7.48 mil
Media Core Diameter
25.4 ~ 38 mm 1” ~ 1.5”
Label length
5 ~ 2,794 mm 0.2“ ~ 110“
Environment Condition
Operation: 5°C ~ 40°C, 25 ~ 85% noncondensing,
Storage: ~40°C ~60°C, 10 ~ 90% noncondensing
